representation of a VLBI observation More...

#include <Observation.h>

Inheritance diagram for VieVS::Observation:

Collaboration diagram for VieVS::Observation:

Public Member Functions
	Observation (unsigned long blid, unsigned long staid1, unsigned long staid2, unsigned long srcid, unsigned int startTime, unsigned int observingTime=0)
	constructor More...

	Observation (const Observation &other)
	copy constructor More...

unsigned long	getBlid () const
	get baseline id More...

unsigned long	getStaid1 () const
	get first station id More...

unsigned long	getStaid2 () const
	get second station id More...

unsigned long	getSrcid () const
	get source id More...

unsigned int	getStartTime () const
	get start time More...

unsigned int	getObservingTime () const
	get observing time More...

bool	containsStation (unsigned long staid) const noexcept
	check if observation is with this station More...

void	setObservingTime (unsigned int observingTime)
	set observing time for this observation More...

void	setStartTime (unsigned int startTime)
	set start time for this observation More...

void	addNoise (double noise)
	add noise to observed minus computed More...

Public Member Functions inherited from VieVS::VieVS_Object
	VieVS_Object (unsigned long id)
	constructor More...

const unsigned long	getId () const
	get object id More...

bool	hasValidId () const
	check if id is valid More...

bool	hasId (unsigned long id) const
	check if object has specific id More...

void	setId (unsigned long id)
	set object id More...

std::string	printId () const
	object id string More...

Static Public Member Functions
static unsigned long	numberOfCreatedObjects ()
	number of created observations More...

Private Attributes
unsigned long	blid_
	baseline id More...

unsigned long	staid1_
	first station id More...

unsigned long	staid2_
	second station id More...

unsigned long	srcid_
	source id More...

double	o_c = 0

double	sigma = 0

unsigned int	startTime_
	observation start time More...

unsigned int	observingTime_
	observation duration More...

Static Private Attributes
static unsigned long	nextId = 0
	next id for this object type More...

Detailed Description

representation of a VLBI observation

Author: Matthias Schartner

Date: 28.06.2018

Constructor & Destructor Documentation

Observation::Observation	(	unsigned long	blid,
		unsigned long	staid1,
		unsigned long	staid2,
		unsigned long	srcid,
		unsigned int	startTime,
		unsigned int	observingTime = `0`
	)

constructor

Author: Matthias Schartner

Parameters

blid	baseline id
staid1	first station id
staid2	second station id
srcid	source id
startTime	start time
observingTime	observing time in seconds

Observation::Observation ( const Observation & other )

copy constructor

Author: Matthias Schartner

Parameters

other reference observation

Member Function Documentation

void VieVS::Observation::addNoise ( double noise )

inline

add noise to observed minus computed

Author: Matthias Schartner

Parameters

noise noise in seconds

bool Observation::containsStation ( unsigned long staid ) const

noexcept

check if observation is with this station

Author: Matthias Schartner

Parameters

staid target station id

Returns: true if observation is between this station, otherwise false

Here is the caller graph for this function:

unsigned long VieVS::Observation::getBlid ( ) const

inline

get baseline id

Author: Matthias Schartner

Returns: baseline id

Here is the caller graph for this function:

unsigned int VieVS::Observation::getObservingTime ( ) const

inline

get observing time

Author: Matthias Schartner

Returns: observing time in seconds

Here is the call graph for this function:

Here is the caller graph for this function:

unsigned long VieVS::Observation::getSrcid ( ) const

inline

get source id

Author: Matthias Schartner

Returns: source id

Here is the caller graph for this function:

unsigned long VieVS::Observation::getStaid1 ( ) const

inline

get first station id

Author: Matthias Schartner

Returns: first station id

Here is the caller graph for this function:

unsigned long VieVS::Observation::getStaid2 ( ) const

inline

get second station id

Author: Matthias Schartner

Returns: second station id

Here is the caller graph for this function:

unsigned int VieVS::Observation::getStartTime ( ) const

inline

get start time

Author: Matthias Schartner

Returns: start time

Here is the caller graph for this function:

static unsigned long VieVS::Observation::numberOfCreatedObjects ( )

inlinestatic

number of created observations

Author: Matthias Schartner

Returns: total number of created observations

Here is the caller graph for this function:

void VieVS::Observation::setObservingTime ( unsigned int observingTime )

inline

set observing time for this observation

Author: Matthias Schartner

Parameters

observingTime observing time in seconds

void VieVS::Observation::setStartTime ( unsigned int startTime )

inline

set start time for this observation

Author: Matthias Schartner

Parameters

startTime start time

Member Data Documentation

unsigned long VieVS::Observation::blid_

private

baseline id

unsigned long VieVS::Observation::nextId = 0

staticprivate

next id for this object type

double VieVS::Observation::o_c = 0

private

unsigned int VieVS::Observation::observingTime_

private

observation duration

double VieVS::Observation::sigma = 0

private

unsigned long VieVS::Observation::srcid_

private

source id

unsigned long VieVS::Observation::staid1_

private

first station id

unsigned long VieVS::Observation::staid2_

private

second station id

unsigned int VieVS::Observation::startTime_

private

observation start time

The documentation for this class was generated from the following files:

/home/travis/build/TUW-VieVS/VieSchedpp/Scan/Observation.h
/home/travis/build/TUW-VieVS/VieSchedpp/Scan/Observation.cpp
